| Frequency range | 70 MHz to 410 MHz | |
| Frequency setting resolution | ILS, VOR | 100 Hz |
| COM, GBAS | 10 Hz | |
| Frequency measurement resolution | 1 Hz | |
| Preselection filter ranges | standard | 70 MHz to 410 MHz |
| with R&S®EVSG-K23 option | ||
| marker beacon | 74.7 MHz to 75.3 MHz | |
| ILS LLZ, VOR | 108 MHz to 118 MHz | |
| COM 1 | 118 MHz to 145 MHz | |
| ILS GS, COM 2 | 220 MHz to 410 MHz | |
| Reference frequency, internal | ||
| Accuracy | (time since last adjustment × aging rate) + temperature drift + calibration accuracy | |
| Aging per year | 1×10⁻⁷ (nom.) | |
| Temperature drift (-10°C to +50°C) | 1×10⁻⁷ (nom.) | |
| Achievable initial calibration accuracy | 5×10⁻⁶ (nom.) | |
| Spectral purity | ||
| SSB phase noise | frequency = 110 MHz, carrier offset | |
| 10 kHz | -105 dBc (1 Hz) (typ.) | |
| 25 kHz | -115 dBc (1 Hz) (typ.) | |
| 100 kHz | -125 dBc (1 Hz) (typ.) | |
| 1 MHz | -145 dBc (1 Hz) (typ.) | |
