| Power rating | |
| Rated voltage | 100 V to 240 V AC (± 10 %) |
| Rated frequency | 50 Hz to 60 Hz (± 5 %), 400 Hz (± 5 %) |
| Rated current | model with 2 HU (R&S®SMAB - B92 option): 3.5 A to 1.6 A (50 Hz to 60 Hz), model with 3 HU (R&S®SMAB - B93 option): 7.5 A to 2.9 A (50 Hz to 60 Hz/400 Hz), 7.3 A to 4.6 A (400 Hz) |
| Rated power | model with 2 HU (R&S®SMAB - B92 option), fully equipped: 300 W (meas.), model with 3 HU (R&S®SMAB - B93 option), fully equipped: 380 W (meas.) |
| Power factor correction | in line with EN 61000 - 3 - 2 |
| Product conformity | |
| Electromagnetic compatibility | EU: in line with EMC Directive 2014/30/EU, applied harmonized standards: EN 61326 - 1 (industrial environment), EN 61326 - 2 - 1, EN 55011 class A, EN 61000 - 3 - 2, EN 61000 - 3 - 3 |
| Electrical safety | EU: in line with Low Voltage Directive 2014/35/EU, applied harmonized standard: UL 61010 - 1 |
| International safety approvals | USA: UL, Canada: CAN/CSA - C22.2 No. 61010 - 1, VDE - Association for Electrical, Electronic and Information Technologies: VDE mark 40045930, CSA - Canadian Standards Association: CSAc mark 70108101 |
| Mechanical resistance | |
| Vibration | sinusoidal: 5 Hz to 55 Hz, 0.15 mm amplitude const., 55 Hz to 150 Hz, 0.5 g const., in line with EN 60068 - 2 - 6, random: 10 Hz to 300 Hz, 1.2 g (RMS) acceleration, in line with EN 60068 - 2 - 64, MIL - STD - 810F, method 514.4, procedure I |
| Shock | in line with EN 60068 - 2 - 27, MIL - STD - 810E, method 516.4, procedure I |
| Environmental conditions | |
| Temperature range | operating, with R&S®SMAB - B36S option: 0 °C to + 55 °C, operating: 0 °C to + 45 °C, storage: - 40 °C to + 71 °C, temperature gradient < 5 K/h |
| Damp heat | operating: + 40 °C, 90 % rel. humidity, steady state, in line with EN 60068 - 2 - 78 |
| Altitude | linear derating of max. ambient temperature to + 45 °C starting at altitude = 3000 m, non - operating: 4600 m (15000 ft), operating: 4600 m (15000 ft) |
| Parameter | Configuration | Value |
|---|---|---|
| Rated current | model with 2 HU (R&S®SMAB-B92 option) | 3.5 A to 1.6 A (50 Hz to 60 Hz), 3.5 A to 2.9 A(400 Hz) |
| model with 3 HU (R&S®SMAB-B93 option) | 7.3 A to 4.6 A (50 Hz to 60 Hz/400 Hz) | |
| Rated power | model with 2 HU (R&S®SMAB-B92 option), when fully equipped | 300 W (meas.) |
| model with 3 HU (R&S®SMAB-B93 option), when fully equipped | 380 W (meas.) |
