| Sensing type | Through-beam type(side sensing type) |
| Sensing distance | 500mm |
| Sensing target | Opaque material of min. Ø5mm |
| Response time | Max. 1ms |
| Light source | Infrared LED(940nm) |
| Operation mode | Dark ON |
| Weight | ≈ 150 g (≈ 200 g) |
| Power supply | 12-24VDC ±10%(ripple P-P: max. 10%) |
| Current consumption | Emitter/Receiver: Max. 30mA |
| Control output | NPN open collector |
| Environment Ambient illumination | Sunlight: Max. 11,000lx, Incandescent lamp: Max. 3,000lx (received illumination) |
| Environment Ambient temperature | -10 to 60℃, storage: -25 to 70℃ |
| Environment Ambient humidity | 35 to 85% RH, storage: 35 to 85% RH |
| Protection structure | IP50 |
| Connection type | Cable type(Ø4, 2m) |
| Material | Case: PC, sensing part: PC, bracket: SPCC, bolt: SCM, nut: SCM |
Detection principle: Reflective type (the transmitter and receiver work together and need to be installed in pairs)
Core function: By using infrared modulated light signals, it can detect the presence or absence of non-transparent objects and determine their positions, and outputs an NPN collector open-circuit signal, which is suitable for the logic control requirements of automation systems.
Applicable objects: Non-transparent solids with an outer diameter of ≥ 5mm (such as metal sheets, plastic parts, paper packaging, etc.)
Weight: Approximately 150g.
Packaging contents: Usually include the sensor body, mounting bracket, bolts and nuts.
