| Main | |
| Product or Component Type | Controller |
| Product Certifications | cULus, CE, ICES-003, FCC part 15 class B, BTL |
| Communication Service | SNMP network management, SMTP e-mail notification, SMTPS e-mail notification, Modbus TCP client, Modbus TCP server |
| Current Consumption | 400 mA |
| Device short name | AS-P-SMK |
| Flame Retardance | UL94V0-5VB |
| IP Degree of Protection | IP20 |
| Depth | 2.5 in (64 mm) |
| Height | 4.5 in (114 mm) |
| Product Weight | 11.3 oz (321 g) |
| Width | 3.5 in (90 mm) |
| Ambient Air Temperature for Operation | 32…122 °F (0…50 °C) |
| Ambient Air Temperature for Storage | -4…158 °F (-20…70 °C) |
| Memory Type | 512 MB RAM, 4 GB flash |
| Standards | FCC CFR 47 part 15, UL 94, UL 916, UL 864 |
| Range | EcoStruxure Building Operation |
| Product brand | Schneider Electric |
| Complementary | |
| I/O limit processor capacity | 464 I/O, 29 modules |
| Material | ABS/PC |
| Product mounting | On base, DIN rail |
| Web services | HTTP server, Programmable scripts : alarm summaries, report management, TLS 1.0 |
| Integrated connection type | USB 2.0 type A, USB type mini B |
| Processor Name | Spear 320s |
| Range compatibility | EcoStruxure Building Operation TB-ASP-W1 terminal base, EcoStruxure Building Operation TB-AS-W1 terminal base |
| Communication port protocol | BACnet, Modbus TCP master RS485, Modbus TCP slave RS485, HTTPS RJ45, HTTP RJ45, LON TP/FT-10 |
| Environment | |
| Relative humidity | 0…95 % |
| Ordering and shipping details | |
| Category | US1BMS180230 |
| Discount Schedule | BMS1 |
| GTIN | 3606481139252 |
| Returnability | Yes |
| Country of origin | LV |
| Packing Units | |
| Unit Type of Package 1 | PCE |
| Nbr. of units in pkg. | 1 |
| Package 1 Height | 4.6 in (11.7 cm) |
| Package 1 Width | 2.2 in (5.7 cm) |
| Package 1 Length | 3.6 in (9.1 cm) |
| Package weight(Lbs) | 9.6 oz (271.0 g) |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 36 |
| Package 2 Height | 11.8 in (30.0 cm) |
| Package 2 Width | 11.8 in (30.0 cm) |
| Package 2 Length | 15.7 in (40.0 cm) |
| Package 2 Weight | 23.080 lb(US) (10.469 kg) |
