| Specification Item | Details |
|---|---|
| Communication Protocols | Supports BACnet IP, BACnet MS/TP, and LONWORKS communication, and also supports Modbus RTU master and M-bus (EN 1434-3). |
| Control Functions | Can be used for a variety of building management applications, including traditional HVAC applications, energy management functions (such as optimum start/stop, night purge, and maximum load demand), and supervisory functions for lighting, sun-blind, heat, and energy metering. |
| Operation Mode | An integrated web server allows local and remote operation through standard browsers. |
| Network Security | When operating in IP networks, private networks (such as VPN) must be used, or protection against the open internet (such as with external firewalls) must be ensured. |
| Cost-Saving Features | Uses the existing standard Ethernet/LAN infrastructure for communication, and the flexible and optional use of onboard I/Os and panel bus I/Os further reduces costs. |
| Technical Features | Four selectable control loop priorities (multitasking), selectable control loop cycle times, and event-driven switching tables; can record the trend of 100 data points. |
| Mounting Method | Suitable for mounting in cabinets, in fuse boxes conforming to DIN 43880 (with a maximum slot height of 4), and can also be vertically mounted on DIN rails. |
| Protection Level | IP20 when mounted on the wall with two accessory MVC-80-AC covers; IP30 when mounted on the cabinet door with the accessory MVC-80-AC 2. |
| Certification | Meets BTL, AMEV as-A, EN 60730, EN 60730-2-9, UL 60730, and UL 96; complies with Ethernet protocol versions IEEE 802.3; supports IP and MS/TP communications as per ANSI/ASHRAE 135-200. |
| Dimension | 102*196*62mm |
