J20AA plasma-sprayed ceramic coating stands up to 3000V DC current protection.
Reaches up to 7,300 rpm limits with efficient C3-loose internal clearance.
Optimized for electric motors, wind turbine generators, and railway traction motors.
| Single Row Ball Bearings | |||
|---|---|---|---|
| Brand | FAG | Weight / Kilogram | 1.438 |
| Minimum Buy Quantity | N/A | EAN | 4047643057921 |
| UNSPSC | 31171504 | Precision Class | ABEC 1 | ISO P0 |
| Enclosure | Open | Rolling Element | Ball Bearing |
| Maximum Capacity / Filling Sixt | No | Internal Special Features | Ceramic Coated Outer Ring |
| Snap Ring | No | Internal Clearance | C3-Loose |
| Cage Material | Steel | Other Features | Deep Groove |
| Inch - Metric | Metric | Harmonized Tariff Code | 8482.10.50.68 |
| Category - BDI | Single Row Ball Bearing | Keyword String | Ball |
| Noun | Bearing | Weight / LBS | 1.46 |
| Bore | 3.15 Inch | 80 Millimeter | Outside Diameter | 5.512 Inch | 140 Millimeter |
| Outer Race Width | 1.024 Inch | 26 Millimeter | ||
| Long Description | Single Row Ball Bearing, 80MM Bore, 140MM Outside Diameter, 26MM Outer Race Width, Open, ABEC 1 | ISO P0; No Filling Oil, No Snap Ring, C3-Loose Internal Clearance, Shot Peened | ||
| Dimension | 80mm x 140mm x 26mm |
| Weight | 1.6kg |
| Delivery Info | Delivery information typically includes delivery times, shipping methods, packaging, etc., which may vary depending on the seller and the location of purchase. |
The FAG 6216-J20AA-C3 is designed as a deep groove ball bearing with electrical insulation properties. Its main function is to prevent electrical current from passing through the bearing, preventing electrical erosion and extending equipment life.
The outer ring features a specialized J20AA oxide ceramic coating sealed with synthetic resin. This layer is capable of withstanding voltages up to 3000V DC to effectively block electrical leakage.
It features an inner diameter of 80mm, an outer diameter of 140mm, and a width of 26mm. It weighs approximately 1.4kg, utilizes a robust steel cage, and runs with a C3-loose internal clearance.
This bearing is highly recommended for electric machinery vulnerable to voltage leaks, including electric motors, railway traction motors, and wind turbine generators.
It has a radial dynamic load rating (Cr) of 77,000 N and a radial static load rating (C0r) of 55,000 N. The bearing has a reference speed of 5,500 rpm and can reach a maximum operating speed of 7,300 rpm.
No, the FAG 6216-J20AA-C3 features an open design without seals on either side. This allows for easier installation and maintenance in operating environments that do not require heavy sealing properties.
