| General Information | |
| Extended Product Type | CI501-PNIO |
| Product ID | 1SAP220600R0001 |
| ABB Type Designation | CI501-PNIO |
| EAN | 4016779661263 |
| Catalog Description | Interface module. PROFINET IO RT device. 4 AI: U, I, RTD. 2 AO: U, I. 8 DI 24VDC. 8 DO 24VDC 0.5A (CI501-PNIO) |
| Long Description | CI501-PNIO: S500 Interface module. PROFINET IO RT device. 4 AI: U, I, RTD. 2 AO: U, I. 8 DI 24VDC. 8 DO 24VDC 0.5A. Extendable by up to 10 I/O modules. |
| Ordering | |
| CN8 | 85389091 |
| Invoice Description | Interface module. PROFINET IO RT device. 4 AI |
| Made To Order | No |
| Minimum Order Quantity | 1 piece |
| Order Multiple | 1 piece |
| Selling Unit of Measure | piece |
| Dimensions | |
| Product Net Weight | 0.136 kg |
| Product Net Depth / Length | 62 mm |
| Product Net Height | 76 mm |
| Product Net Width | 67.5 mm |
| Gross Weight | 0.16 kg |
| Package Level 1 Depth / Length | 84 mm |
| Package Level 1 Height | 72 mm |
| Package Level 1 Width | 71 mm |
| Package Level 1 Units | 1 carton |
| Certificates and Declarations | |
| Declaration of Conformity - CE | 3ADR980140 |
| REACH Date | 20241206 |
| REACH Declaration | 3ADR980139 |
| REACH Information | True - contains substances > 0.1 mass percentage |
| SCIP | a307b9ae-b352-4d4d-8ebf-99c63e467033 Germany |
| RoHS Date | 2010 |
| RoHS Declaration | 3ADR980140 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment |
| Technical | |
| Function | PROFINET IO RT device. 4 AI |
| Number of Hardware Interfaces | Industrial Ethernet 2 Other 0 Parallel 0 RS-232 0 RS-422 0 RS-485 0 Serial TTY 0 USB 0 Wireless 0 |
| Analog Inputs | 4 |
| Analog Outputs | 2 |
| Number of Digital Inputs | 8 |
| Number of Digital Outputs | 8 |
| Number of Digital Configurable I/Os | 0 |
| Input Voltage Type | DC |
| Input Voltage (Uin) | 24 V DC |
| Input Current | 5 mA |
| Delay Time | 0.1 ... 32 ms |
| Output | Transistor |
| Output Voltage Type | DC |
| Output Current | 0.5 A |
| Output Voltage Maximum | 20.4 ... 28.8 V |
| Degree of Protection | IP20 |
| Supply Voltage | 20.4 ... 28.8 V DC |
| Product Main Type | CI501 |
| Product Name | Distributed Automation I/Os |
| External Classifications and Standards | |
| eClass | 27-24-26-07 |
| ETIM 8 | EC001604 - Fieldbus, decentr. periphery - communication module |
| ETIM 9 | EC001604 - Fieldbus, decentr. periphery - communication module |
| ETIM 10 | EC001604 - Fieldbus, decentr. periphery - communication module |
| UNSPSC | 32151705 |
| Environmental | |
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
