RFID Capability: Supports UHF RFID (EPC Gen 2 v2 / ISO 18000-63) with a reading range of up to 7.6 meters. It enables fast batch scanning of multiple tags simultaneously, improving inventory efficiency.
Barcode Scanning: Integrated SE4710 1D/2D scan engine, capable of decoding worn, smudged, or low-contrast barcodes. It complements RFID for mixed media (tag + barcode) tracking scenarios.
Processor & Storage: Equipped with a Qualcomm Snapdragon octa-core processor, paired with 4GB RAM and 64GB flash storage. Supports microSD expansion up to 1TB for large data storage.
Display & Input: 5.5-inch HD+ (1440×720) touchscreen with 500 nits brightness. The display is scratch-resistant (Corning Gorilla Glass) and supports glove/stylus input, adapting to harsh environments.
Battery Life: 3.85V, 4000mAh rechargeable lithium-ion battery. Delivers all-day usage on a single charge, with optional fast charging to minimize downtime.
Rugged Standards: Meets MIL-STD-810H military certification, withstanding 1.2-meter drops onto concrete. IP65 rating for dust and water resistance, protecting against splashes and debris.
Operating Temperature: Works in -10°C to 50°C, suitable for indoor warehouses, outdoor yards, and field service scenarios.
Wireless Connections: Supports Wi-Fi 6 (802.11ax), Bluetooth 5.2, and optional 4G LTE (with nano-SIM). Ensures stable data transmission in large facilities or remote areas.
Software & Security: Runs on Android 12 (upgradable) with Zebra's Link-OS. Enables centralized remote management, security updates, and custom app deployment. Supports enterprise-grade encryption for data protection.
Dimensions & Weight: 165×79×22.7mm (L×W×H), weighs 290g (with battery). Ergonomic design for comfortable one-hand operation during long shifts.
| Specifications | Details |
|---|---|
| Physical Characteristics | |
| Dimensions | 5.7 in. H x 3.3 in. W x 6.96 in. L 14.5 cm H x 8.4 cm W x 17.7 cm L |
| Weight | 20.07 oz. / 569 g |
| Display | 6.0 in. color Full High Definition+ (1080 x 2160), LCD backlight, 450 nits |
| Touch Panel | Multi-mode capacitive touch with bare or light gloved fingertip input |
| Power | User-removable, quick-release, rechargeable 7000 mAh Li-Ion battery with PowerPrecision+ for real-time battery metrics |
| Network Connections | WLAN, WPAN |
| Notifications | Audible tone, vibration |
| Indicators | Decode LEDs, battery status LED, beeper |
| Keypad | On-screen keypad |
| Buttons | User-programmable button for barcode scanning (default), PTT or other use, volume up/down, power |
| User Input | Tri-function user-programmable trigger |
| Interface Ports | USB 3.1 (Bottom Type C), Super Speed (host and client) |
| User Environment | |
| Operating Temperature | 14° F to 122° F / -10° C to +50° C |
| Storage Temperature | -40° F to 158° F / -40° C to +70° C |
| IP Sealing | IP65 |
| Humidity | 5–95% non-condensing |
| Electrostatic Discharge | ±15 kV air discharge ±8 kV direct discharge |
| Tumble Specification | 500 cycles (1,000 drops, 1.6 ft. /0.5 m) at room temperature |
| Drop Specification | Multiple 5 ft. /1.5 m drops to concrete |
| Performance Characteristics | |
| CPU | 5430 hexa-core 2.1 GHz |
| Operating System | Android: for supported versions, visit www.zebra.com/android-versions |
| Memory | 6 GB RAM / 64 GB Flash |
| RFID Characteristics | |
| Standards Supported | EPC Class 1 Gen 2; EPC Gen 2 V2 |
| RFID Engine | Zebra Proprietary Radio Technology |
| Maximum RFID Read Rate | Up to 1,300 tags/sec |
| Nominal RFID Read Range - Integrated Antenna | 40 ft. / 12.2 m |
| Frequency Range and RF System Output | US: 902–928 MHz; 0–36 dBm (EIRP) EU: 865–868 MHz; 0–33 dBm (ERP) 916.3, 917.5, and 918.7 MHz; 0–36 dBm (ERP) Japan: 916–921 MHz (w LBT), 0–36 dBm (EIRP) |
