Low Backlash Design: Standard backlash as low as 3 arc minutes (1 arc minute for select models), delivering high repeatability for positioning-critical applications.

High Load Capacity & Shock Resistance: Leverages a unique cycloidal structure with 2/3 tooth engagement, allowing it to withstand 300% instantaneous shock loads. Output torque ranges from 4.9 to 588 N·m.

High Efficiency & Low Noise: Rolling contact transmission minimizes friction, achieving transmission efficiency exceeding 95% with operational noise below 65 dB.

Motor Compatibility: Power-matched for 0.1–7.5 kW servo motors, with reduction ratios ranging from 3:1 to 100:1. Supports single-stage/two-stage configurations.

Multiple Mounting Options: Offers flange, base, and shaft mounting configurations. The compact body allows horizontal or vertical installation in any orientation.

Easy Maintenance: Prefilled with long-life grease for near-maintenance-free operation. Features an IP65 dust and water-resistance sealed structure.

Transmission components utilize vacuum-degassed bearing steel with full hardening treatment for superior wear resistance.

The housing is constructed from high-strength aluminum alloy or cast iron, achieving a lightweight design while maintaining optimal rigidity.

The input shaft employs a flexible coupling design for motor connection, effectively absorbing installation misalignment and vibration to extend overall service life.

Optimized for precision motion control, this series is highly suitable for:

• Industrial robot joint drives

• Precision assembly lines for electronic devices

• Automated inspection equipment and medical devices

• Scenarios requiring high-frequency start/stop cycles and precise positioning
