| Specification | Description |
|---|---|
| Frequency range | 5 kHz - 3 GHz (upgradable, base model is 5 kHz - 1 GHz) |
| Frequency resolution | 1 Hz |
| Marker resolution | 0.1 Hz |
| Displayed average noise level (DANL) | < -142 dBm, typical -150 dBm (without preamplifier); < -158 dBm, typical -165 dBm (with preamplifier) |
| Third-order intercept (TOI / IP3) | > +7 dBm (measured) |
| Level measurement uncertainty (at 100 MHz) | < 0.3 dB (+20 °C to +30 °C) |
| Resolution bandwidth (RBW) | 1 Hz - 3 MHz |
| Maximum input power | Up to +30 dBm |
| Input impedance | 50 Ω (nominal) |
| Display type | WXGA |
| Display size | 10.1-inch (25.6 cm) |
| Display resolution | 1366 × 768 pixels |
| Interfaces | LAN, 2x USB, Wi-Fi (optional) |
| Dimensions (without feet) | 396 mm × 147 mm × 178 mm |
| Dimensions (with feet) | 396 mm × 156 mm × 185 mm |
| Weight | 3 kg |
| Minimum operating temperature | +10 °C |
| Maximum operating temperature | +40 °C |
The base instrument operates from 5 kHz to 1 GHz, and its frequency range can be upgraded to 3 GHz via software keycode options.
It is equipped with a 10.1-inch color WXGA display (1366 × 768 pixels). This display size is 26% larger, and the resolution is 160% higher than other instruments in its class.
The R&S®FPC1000 supports wired Ethernet and Wi-Fi connectivity. It can be remotely managed via Instrument View for Windows or via the Mobileview app available for iOS and Android devices.
Without a preamplifier, the DANL is typically < -142 dBm. With the preamplifier enabled, it drops to < -158 dBm, and is typically around -165 dBm.
The instrument features a built-in VSWR bridge, a tracking generator, an independent CW signal generator, and operates as a one-port vector network analyser capable of displaying Smith charts.
Without feet, the unit dimensions are 396 mm × 147 mm × 178 mm and it weighs 3 kg, making it a highly compact and portable solution. It is also equipped with a lithium battery.
