| Specification | Details |
|---|---|
| Resistance Range | 0.01Ω - 2000Ω |
| Resistance Accuracy | 2% ± 3 digits (2-pole and 3-pole testing); 5% ± 3 digits (ART testing) |
| Maximum Probe Resistance | RP limit: 100kΩ (50V output voltage); RC limit: 100kΩ (50V output voltage). Limits reduced to 50kΩ for 25V output voltage; limits reduced to 5kΩ for 0.01Ω resolution on 18Ω range |
| Earth Voltage Range | 0 - 100V a.c. |
| Earth Voltage Accuracy | 2% ± 2V |
| Earth Current Range (with MCC Clamp) | 0.5mA - 19.9A |
| Earth Current Accuracy | 5% ± 3 digits |
| Test Voltage | 25V or 50V (selectable) |
| Test Current | 4.5mA |
| Test Frequency | 128Hz |
| Display | LCD |
| Power Supply | 8 x AA batteries |
| Operating Temperature Range | -15°C to +55°C |
| Storage Temperature Range | -40°C to +70°C |
| Dimensions | 203mm x 148mm x 78mm (8 x 5.7 x 3.2 inches) |
| Weight | 1kg |
| Safety Rating | CAT IV 100V |
| IP Rating | IP54 |
